Two and Three Axis Gyroscopes (TAG)
The Inertial Labs Axis Gyroscopes are developed for Electro-Optical Systems, Gimbals, Line-of-Sight, and Pan and Tilt Platforms for inertial stabilization and pointing applications. These devices utilize advanced, tactical-grade MEMS sensitivity whose size, power consumption, reliability, and performance are ideal for accomplishing complex tasks requiring accurately stabilizing assorted platforms.
The TAG units are factory-calibrated over their operational temperature range and precision machined to ensure low non-orthogonality and misalignment between sensitive elements. Additionally, these items are ITAR-free and exportable (ECCN 7A994) to available countries. Each unit is supplied with individual Calibration and Acceptance Test Certificates and goes through extensive Quality Assurance and Quality Compliance procedures to ensure product reliability before shipping.
The Inertial Labs team of skilled engineers provides expertise to help users select and configure available models. Our skilled support team helps set up units for all application bases to satisfy environmental and circumstantial project requirements.
TAG Models
 |
 |
 |
|
| TAG-207 | TAG-307 | TAG-304 | |
| Two Axis Gyroscope | Three Axis Gyroscope | Three Axis Gyroscope | |
| Number of Axes | Two | Three | Three |
| Measurement Range | ±450 deg/sec | ±450 deg/sec | ±2000 deg/sec |
| Data Update Rate | 4000 Hz | 4000 Hz | 4000 Hz |
| Bias in-run Stability | 0.45º/hour (Allan Variance, RMS) | 0.45º/hour (Allan Variance, RMS) | 2º/hour (Allan Variance, RMS) |
| Noise (ARW) | 0.06º/√hour | 0.06º/√hour | 0.2º/√hour |
| Size (mm) | 39 x 45 x 22 | 39 x 45 x 22 | 19.5 x 15.2 x 5.5 |
| Weight (gram) | 70 | 70 | 10 |
| Applications | Anti-Roll Systems, Computer Pointing Devices, Optical Image Stabilization | Three Dimensional Optical Image Stabilization, Virtual Reality | Guidance & Navigation, Electro-Optical Systems, Gimbals, Line-Of-Site and Pan & Tilt Platforms stabilization and pointing applications. |
| Model | TAG-207 | TAG-307 | TAG-304 |
| Datasheet |
Use Cases for the TAG
Remote Weapon Stations (RWS) Stabilization
A Remote Weapon Station (RWS), or a Remote-Controlled Weapon Station (RCWS), is a commonly used military-oriented fire-control system for both light and medium caliber weapons. An RWS can be used in simulating fire control systems for training purposes and main missions in the line of fire. The TAG units are commonly used to stabilize these platforms and can be integrated with additional components such as Optical Aiding Data (stereo cameras), GNSS receivers for heading calculations, or object recognition software.Optical Image Stabilization (2D and 3D)
Easily integrate with electro-optical systems to stabilize platforms and use information supplied by the TAG for object recognition, detection, and end-to-end response systems. Computer vision systems utilize data streams from the Inertial Labs TAG to correctly identify target position, range distance, and elevation angle.
Stabilization and Anti-Roll Systems
The Axis Gyroscope is an ideal stabilization and anti-roll solution in static and dynamic applications. The TAG-307 is ideal for gimballed rocket engines to vector thrust in different directions in the aerospace industry. For land vehicles, utilize the TAG-207 to stabilize independently operated remote weapons stations and offset vehicle pitch and roll.
TAG Supported Software
Inertial Labs supplies drivers and necessary tools for easy integration with commonly used platforms such as ROS, LabVIEW, and Waypoint products. Additionally take advantage of the Software Development Kit to create custom solutions for your application.
SDK
LabVIEW
ROS
Performance Characteristics for the TAG
TAG Gyroscope Noise, Allan Variance Test
Development Kit
